DJI AS1 Speaker
DJI · AIQ-0004
A 90 g speaker for the Matrice 4 and 4D Series: 114 dB at 1 m, broadcasting up to 300 m.
- Sound pressure level114 dB @ 1 m
- Maximum broadcast distance300 m
- Weight90 g
Overview
About this product.
The AS1 is a compact speaker for the Matrice 4 and Matrice 4D Series, reaching 114 dB at 1 m and broadcasting up to 300 m.
It plays live from the controller, plays back recorded audio, and converts typed text to speech: in Mandarin Chinese and English. Echo suppression keeps the aircraft’s own noise out of a live broadcast.
At 90 g excluding the bracket it costs very little payload capacity, and it operates from -20°C to 50°C. Fitted to a Matrice 4D Series aircraft it is rated IP55.
Key capabilities
- 114 dB at 1 m, up to 300 m broadcast
- Live broadcast, recorded playback and text-to-speech
- Text-to-speech in Mandarin Chinese and English
- Echo suppression
- 90 g excluding bracket
Typical applications
Public safety announcements, site communication, and search and rescue.
Technical data
Specifications.
| Audio | |
|---|---|
| Sound pressure level | 114 dB @ 1 m |
| Maximum broadcast distance | 300 m |
| Text-to-speech languages | Mandarin Chinese, English |
| General | |
| Weight (excluding bracket) | 90 g |
| Ingress protection (with Matrice 4D Series) | IP55 |
| Operating temperature | -20 to 50 °C |
Questions
Questions we’re asked.
The speaker
What can the AS1 do?
Record and broadcast, play imported files, and text-to-speech in English and Mandarin, with live broadcast and echo suppression. It works alone or stacked with the AL1 spotlight.
Which aircraft does it fit?
The Matrice 4D Series and the Matrice 4 Series. On the 4D Series the bottom bracket is removed first.
How is it installed?
Fit it before powering the aircraft on, tighten the screws for the seal (and re-tighten with the hex key when it flies from a dock) then connect to the internet to activate and calibrate the compass. It updates with the aircraft firmware.
What changes in use?
Flight time and power margin drop. Use the standard controller and speak close to its microphone at a steady pace; play voices rather than single tones; do not use it near people or noise-sensitive places. Start and stop shortcuts live in DJI Pilot 2’s custom buttons.
Compatibility
Compatible aircraft.
- Matrice 4E
- Matrice 4T
- Matrice 4D
- Matrice 4TD
